Everything was silent.
The one that has been lying in my junk pile for a long timekpowerServo, like a sleeping warrior, is steady and completely motionless. Its axis of rotation stubbornly stays at the zero degree position, as if asking: "Do you know how to wake up my muscles and bones?".
I pressed the button on the remote control, and an invisible infrared light shot towards it, like throwing a stone to ask for directions. Has it moved? Not so. Why is this? Just because that light was just an arrow without feathers in the arsenal, and it did not carry any military orders.
From 0 to 180, these five simple words are just the starting and ending points of an arc for those who have just entered this field. However, in the eyes of those of us, this is a strict set of "palace etiquette." The key point of changing the infrared remote control servo from 0 to 180 is not to rely on brute force, but to rely on "etiquette".
Please listen to me carefully.
In order to make the servo arm rotate from the freezing point to the boiling point, three things are needed, one of which is indispensable.
Manufacture (letter): infrared remote control. This is a monarch, he just doesn't say a word, his words are as heavy as a mountain. Each button corresponds to a unique string of "fire-painted cipher text".
Its components include: a module for infrared reception, and a steering gear. Among them, the receiving module plays the role of a ceremonial supervisor in the palace, quietly waiting for the imperial edict to be issued; while the steering engine is like a royal guard, and will take action as soon as it hears the order.
The soul (Dharma) has codes and mappings. The king issued a decree, the content of which was "rotate 90 degrees", and the ceremonial supervisor had to translate this meaning into "pulse words" that the guards could understand.
The mistake in frequent meetings is to mistake "secret text" for "military orders."I once saw a person who had just started learning use the TV remote control to command the servo to operate. The keycaps of the remote control fell off one after another when he pressed it. However, the servo was as unresponsive as an old monk in a state of trance.. Why is this? Probably because the encrypted text is the "mute" and "change channel" instructions for the TV. How can the operating logic of the servo obey such instructions?
The key lies in success. What is the key to success is to let the steering gear, let the steering gear behave, let the steering gear "understand", "understand" what, "understand" the remote control, a specific button in the remote control, the "language" of a specific button. This is what suddenly becomes clear, and this is the key to success.。
This process cannot be accomplished overnight. It should be done step by step like a cook undressing an ox.
We must first teach the "Supervisor of Ceremonies" to identify the "Jade Seal of the Founding of the People's Republic of China" pressed by the monarch. Common infrared libraries on the market, such as IRremote, are like a "World Translation". Prepare a "probe" program to make the receiving module report what kind of "paint" it received.
Situation example: If you press the "power button" and the serial port monitor prints "0xFFA25D", this is what the "Jade Seal of the Founding of the People's Republic of China" really looks like. If you don't get feedback, don't blame the servo, check the wiring. Signal wires, power wires, and ground wires are like the three legs of a tripod. If one of them is missing, it will fall over.
Once you get the appearance of the jade seal, you can start drafting the imperial edict. The rotation of the servo is controlled by the pulse width of the PWM signal. 0 degrees corresponds to 0.5 milliseconds, 90 degrees corresponds to 1.5 milliseconds, and 180 degrees corresponds to 2.5 milliseconds. This is an "iron law" and will not be changed.
I need to write the words "if '0xFFA25D' is received, then the servo will rotate to 180 degrees" into the code. This is mapping. It looks simple on the surface, but it's actually the key point.
Just here, press the control instrument, and the steering gear will jump from 0 degrees to 180 degrees in an instant like a frightened rabbit. However, this is not a regular state of "from 0 to 180", this is a "teleportation". The true meaning of "from 0 to 180" should be like a gentle smoke rising slowly.
If you want to reach this point, you need to introduce the idea of "step by step". Never let it reach 180 directly, but let it reach 1 degree, then 2 degrees, and so on until it reaches 180. It's like climbing a hundred-foot-tall building, one step at a time, rather than jumping up all at once.
Q1: Why does the servo not move at all when I press the remote control?
First, check whether the "three wires" are loose. Next, check whether the receiving head has received a signal (observe its indicator light). In most cases, there is a wiring error.
Q2: The servo is vibrating wildly and cannot stop at the specified angle?
A: The power provided by the power supply is insufficient. The steering gear behaves like a hungry person snatching food, which requires sufficient current. It is recommended to use an independent power supply method and never share the power supply with logic circuits.
Q3: How to make the servo rotate slower like a pendulum?
In the "step by step" loop situation, a small delay is added. The longer the delay lasts, the slower it will move.
Q4: My remote control key code is different from the one in the tutorial, what should I do?
It said that this is a normal state. You cannot apply it rigidly. You must use the "probe" program to actually measure and record the shape of your unique "jade seal".
Q5: Can you press it once to rotate 45 degrees and press it again to rotate 90 degrees?
Yes, set a variable as the "current position", and each time it is pressed, it will accumulate 45 degrees. Once it exceeds 180 degrees, it will return to zero. This is the preliminary form of the "state machine", and this is the arrangement.
Some people may ask: "It's just a rotating steering gear, what's the use of adjusting it?"
Can't you see that in the greenhouse in the cold winter, an infrared probe is monitoring the temperature. Once the temperature drops, the servo will slowly turn to open the air vent. This is the so-called "intelligent farming"; you can't see that in the study room at night, an infrared sensor device, as long as it detects someone, will let the servo drive the desk lamp to deflect, and the light will move with the person. This is "knowledge through investigation".
I once met a ceramics craftsman who was troubled by the inconvenient control of the fire outlet valve of the kiln. Based on this set of principles, I made a remote control adjustment system for him. At the beginning, the craftsmen regarded it as child's play. When he saw with his own eyes that the servo smoothly pushed the valve from closed to fully open like dancing sleeves, he had a look of surprise on his face and exclaimed: "Although this thing is small, its effect is huge!".
This is the true connotation of "from 0 to 180": it not only means perspective, but also moves from "rigid" to "flexible", from "chaos" to "normative", and from here to "achievement". What is carried on the curved track is no longer a simple mechanical arm, but a small magical power that can be touched and change the surroundings.
> sudden enlightenment
According to this method, the system is constructed and the remote control is pressed. The so-called "imperial bodyguard" will no longer teleport without warning.。
You will see it slowly turning its body with a speed that is perceptible to the naked eye, showing grace and unmistakable momentum.
0 degrees...30 degrees...90 degrees...180 degrees.
The gesture when it reaches the end is confident and complete, like a general sheathing his sword.
However, the infrared signal that started all the processes had now completed its mission and gradually disappeared in the air. However, your creation has just begun. It stayed there steadily, waiting for the next summons from the void.
That pause is a blank space and an invitation. Please, give me another order.
