Most standardservomotors have a rotation angle range of 0 to 180 degrees, with the neutral position at 90 degrees. This means a typicalservocan move its output shaft from one extreme (0°) to the opposite extreme (180°) when commanded by a pulse-width modulation (PWM) signal. However, someservos are designed for 90°,270°, or continuous rotation. Understanding these limits is critical for robotics, RC vehicles, and automation projects. Below you will find the exact angle specifications for common servo types, verified by manufacturer datasheets and practical testing, along with actionable steps to confirm your servo’s actual range before building your mechanism.
The vast majority of hobby and educational servos follow the 0–180° standard. For example, a typical SG90 or MG996R servo will stop at 0° when receiving a 1.0 ms pulse and at 180° with a 2.0 ms pulse (neutral at 90° with 1.5 ms).
Real-world example:In a robotic arm joint, using a 180° servo allows the arm to lift from horizontal (0°) to vertical (180°). Designers must account for mechanical stops inside the servo; exceeding commanded angles will not damage the servo but will not produce additional motion.
Some servos are built for narrower or wider ranges:
90° servos:Often used in steering mechanisms of small RC cars. A 90° range (e.g., –45° to +45° relative to neutral) gives precise control for rack-and-pinion steering.
120° servos:Common in pan-tilt camera mounts where a moderate field of view is sufficient.
270° servos:Used in sail winches or industrial valve actuators. These have different internal potentiometer gearing and can rotate three-quarters of a full circle.
Practical note:Always check the product datasheet’s “maximum mechanical angle” – some 270° servos can be programmed to 180° or 360° via external controllers.
A continuous rotation servo is not suitable for position control. It behaves like a geared motor: the PWM signal controls speed and direction, not a specific angle.
Common misconception:Users often buy a continuous servo expecting 360° positioning. In reality, it provides infinite rotation but zero angle feedback. For applications needing full rotation with positioning (e.g., a robotic wrist), use a standard servo with a 360° modification or a stepper motor.
To avoid mechanical binding or incomplete motion, follow this test procedure:
![]()
1. Read the datasheet– Look for “operating angle” or “adjustable range”. Reputable brands list these values.
2. Perform a sweep test– Use an Arduino, servo tester, or PWM generator. Send the minimum pulse (usually 0.5–1.0 ms) and record the angle; then send the maximum pulse (1.5–2.5 ms) and record the angle.
3. Check for physical stops– Gently rotate the output shaft by hand when powered off. A standard servo will stop at about 0° and 180° due to internal gear stops.
4. Use a protractor– Attach a pointer to the servo horn and mark actual start and end positions. This gives you the true mechanical range, which may be 170–175° due to tolerances.
Key takeaway:Never assume a servo provides exactly 180°. Test each unit, especially when using multiple servos in a synchronized system.
Pulse width limits:Sending a 2.5 ms pulse to a standard servo may push it to 190°, but this risks damaging the potentiometer. Stay within datasheet specifications (typically 1.0–2.0 ms).
Load and power supply:Under heavy torque, the servo may not reach its full commanded angle. Use a power supply rated for the servo’s stall current.
Programming libraries:Some libraries (e.g., Arduino’s Servo.h) default to 0–180° mapping. You can changewriteMicroseconds()values to access a wider range if the servo supports it.
The core point to remember is that most servos rotate 0 to 180 degrees, but exceptions exist from 90° to continuous rotation. Do not rely on general statements like “servo goes 180°” without verifying the actual unit in your hand.
Actionable recommendation: For any new project, spend 5 minutes running a sweep test with a servo tester or microcontroller. Record the exact minimum and maximum angles for each servo. Design your mechanical linkages with a 5–10° safety margin (e.g., if your servo moves 0–180°, limit your software commands to 10–170°) to prevent binding and extend servo life. This simple habit will eliminate 90% of motion-related failures in prototypes.
